Add an Instance

Database Instance or simply Instance models after a single database instance which is usually accessed via a host:port address. A typical database instance could be your on-premises MySQL instance, an AWS RDS instance etc. Each Database Instance belongs to an Environment.

Prerequisites

• Workspace Owner or Workspace DBA role
• A database instance. If you don't have an existing instance on hand, you can add a local MySQL instance.

Add an instance

1. Click Instances on the top bar.
2. Click Add Instance.
3. Select an Instance Type on the top.
4. Enter Instance name, select Environment. Note: Environment cannot be changed once the instance has been created.
5. Enter Host or Socket and Port.
6. Enter connection info: Username and Password, and click Test Connection.
7. (Optional) Enter SSL connection info:
   1. Choose None to not use SSL connection.
   2. Choose CA Certificate to use SSL connection with CA certificate only.
   3. Choose CA Certificate + Client Key + Client Certificate to use a full SSL connection.

info

The screenshot assumes you run Bytebase inside Docker and try to connect to a database instance on the same host. Thus it uses host.docker.internal. If Bytebase is not running inside Docker, you should supply the normal 127.0.0.1 to connect the instance on the same host. Check out Configure Instance Connection for the detailed configuration guide.

After adding an instance, click Databases on the navigation bar. You can find the table is still empty. It’s because you haven’t created any project yet. In Bytebase, only databases belong to a user project will show up on the Databases page.
